PF Series Fiberglass Media Pocket Filter
Overview
Engineered to enhance Indoor Air Quality (IAQ), the PF Series pocket filters adopt fiberglass media featuring high dust-holding capacity. They help extend the service life of high-efficiency filters under both constant and variable-air-flow operating conditions.
Specifications
- Media: High-quality fiberglass
- Frame: Solid galvanized steel for header and mounting. Metal clinching construction without rivets; smooth-edged, robust build.
- Recommended Final Resistance: 1.5″ W.G. (375 Pa)
- U.L. Classification: U.L. Class 2
- Maximum Operating Temperature: 60℃
Efficiency & Media Color
| Media Color | Efficiency |
|---|---|
| Yellow | 90–95% |
| Pink | 80–85% |
| Orange | 60–65% |
| Green | 40–45% |
Custom sizes are available, with guaranteed filter performance.
Note: The attached photo shows a pink-media sample (80–85% efficiency) with galvanized-steel frame for reference only. Other colour-coded media grades are available upon request.
